YF-CNC8322
CNC 3-Axis Spring Forming Machine
Unbeatable Value — The Most Cost-Effective 3-Axis Spring Machine in China
In Stock | Fast Delivery within 3-7 Working Days
Key Features & Advantages
- High-Speed Precision: Designed with a cam mechanism, ensuring fast operation, superior precision, and excellent stability.
- Advanced Control System: Equipped with Taiwan’s computer control system and Japanese-imported servo motors for reliable performance.
- Stable Wire Feeding: Features a vertical feeding mechanism for enhanced stability and easier debugging during setup.
- User-Friendly Interface: The bilingual Chinese-English computer interface ensures simple and intuitive operation.
Versatile Spring Production
Our CNC 3-axis spring forming machine is ideal for manufacturing a wide range of springs and wire forms, including:
- Double tension springs
- Straight springs
- Pagoda compression springs
- Rectangular springs
- Wire forming parts
- Steel vortex springs
- Custom fancy and shaped springs
Why Choose Our CNC 3-Axis Spring Machine?
✅ Best Price-to-Performance Ratio in China
✅ Fast Delivery — Ships in Just 3-7 Working Days
✅ Ideal for Both Small Batches and Large-Scale Production
✅ Reliable After-Sales Support & Free Training
For businesses seeking maximum productivity and cost-efficiency, our CNC 3-axis spring forming machine is the ultimate solution. Contact us today for a quote!
Technical Parameters:
| Model | CNC-8322 | CNC-8335 | CNC-8345 | CNC-8350 | |
| Color | Grey/Blue (customized) | Grey/Blue (customized) | Grey/Blue (customized) | Grey/Blue (customized) | |
| Diameter of the steel wire(mm) | Φ0.3-Φ2.5mm | Φ1.0-Φ3.5 | Φ1.5-Φ4.5 | Φ2.0-Φ5.0 | |
| Total power (kw) | 6.9 | 11.2 | 13.2 | 17 | |
| Number of axes | 3-4 | 3-4 | 3-4 | 3-4 | |
| Number of the wire feed wheel | 3 pairs | 3 pairs | 3 pairs | 3 pairs | |
| Servo motor | Wire feeding | 2.7kw | 4.5kw | 5.5kw | 7kw |
| Core | 0.75kw | 1kw | 1kw | 1.5kw | |
| Spinner | 0.75kw | 1.2kw | 1.2kw | 1.5kw | |
| Camshaft | 2.7kw | 4.5kw | 5.5kw | 7kw | |
| Main Machine(L*W*H)(mm) | 1300*600*1800 | 1700*980*2100 | 1700*1000*2100 | 1900*1200*2200 | |
| Net Weight of Machine (kg) | 800 | 1900 | 1950 | 2550 | |
After-Sales & Training
1. Our product is life-time warranty from B/L Date. Parts damaged during 12 months from B/L date will be replaced on the cost of the SELLER. But the carriage fee is borne by the buyer.
2. Seller provides the service for the buyer forever. Buyer can contact us by Skype, WhatsApp, Email and Telephone at any time. We provide 24h on-line service.
3. Buyer need mounting service and training abroad, all costs will be charged: visa, round flight tickets,boarding & lodging, labor charge of one engineer 150USD PER DAY.After receiving all the cost, seller willsend engineer to Buyer’s site.
4. Buyer need send 1-2 persons to Seller’s company for training. Training fee was borne by Seller. The flight ticket and the boarding & lodging expense should be borne by Buyer.
Tension Spring
Torsion Spring
Battery Compression Spring Redux Spring Double Wire Spring
Clothespin spring Zigzag Spring
Constant Spring
